Large Format Curved Projection Screens for Simulator System
Curved Projection Screen, Silver Curved Screen, 3D Screen, 360 degree curved Screen for a flight simulator, Projection Screen for Flight SimulationWe make curved screens, screens for active and passive 3D simulator screens and simulation displays. Curved Frame Screen is a customized product that is ......
Send Inquiry
Product Description
Curved Projection Screen, Silver Curved Screen, 3D Screen, 360 degree curved Screen for a flight simulator, Projection Screen for Flight Simulation
We make curved screens, screens for active and passive 3D simulator screens and simulation displays. Curved Frame Screen is a customized product that is made-to-order for each customer. For the curved screen, a unique material is applied to the frame that is specially manufactured to ensure that the screen has no creases and high smoothness. Any degree and shape of the screens are available for single or multi-projector displays. All curved screens are available in a design format, custom sizes, FOV, and Radii
Curved Front Projection
We create curved displays from rigid substrates or from flexible screen material stretched over specially designed frames. Projector mounts can be constructed around virtually any cockpit or cab and set up with projectors edge-blended to give a near perfect seamless display around a complete 180° field of view.
Segmented Front Projection
Using rigid or flexible screens we can create multiple channel systems to give the possibility of displays with up to 360° field of view. In these applications, the projectors use hard edge blending, but the images can be exactly positioned to leave only a hairline join.
PRODUCT FEATURES
» Gives a sense of immersion
» For Cinema
» For Visualization Applications
» For Multi-channel Simulation Displays
» Excellent for museum or exhibitions
» Excellent for training simulators : flight simulators, driving simulators, military simulators
APPLICATIONS
» Cinema
» Museums, Theme Parks, Galleries
» Gaming, Entertainment
» Control Room
» Training Simulators (Flight Simulators, Driving Simulators, Military Simulators)
» Government Projects
» Education
Screen Parameter
FRONT&REAR PROJECTION
We make curved screens, screens for active and passive 3D simulator screens and simulation displays. Curved Frame Screen is a customized product that is made-to-order for each customer. For the curved screen, a unique material is applied to the frame that is specially manufactured to ensure that the screen has no creases and high smoothness. Any degree and shape of the screens are available for single or multi-projector displays. All curved screens are available in a design format, custom sizes, FOV, and Radii
Curved Front Projection
We create curved displays from rigid substrates or from flexible screen material stretched over specially designed frames. Projector mounts can be constructed around virtually any cockpit or cab and set up with projectors edge-blended to give a near perfect seamless display around a complete 180° field of view.
Segmented Front Projection
Using rigid or flexible screens we can create multiple channel systems to give the possibility of displays with up to 360° field of view. In these applications, the projectors use hard edge blending, but the images can be exactly positioned to leave only a hairline join.
PRODUCT FEATURES
» Gives a sense of immersion
» For Cinema
» For Visualization Applications
» For Multi-channel Simulation Displays
» Excellent for museum or exhibitions
» Excellent for training simulators : flight simulators, driving simulators, military simulators
APPLICATIONS
» Cinema
» Museums, Theme Parks, Galleries
» Gaming, Entertainment
» Control Room
» Training Simulators (Flight Simulators, Driving Simulators, Military Simulators)
» Government Projects
» Education
Screen Parameter
FRONT&REAR PROJECTION
| Description | HD Flexible White | HD Flexible Gray | Flexible Perforated | 3D Silver(Flexible) | 3D Silver(Hard) | Rear Gray(Flexible ) | |
| Brightness(Gain) | 1.0 | 0.9 | 1.2 | 2.5-2.8 | 0.8-4.0 | 3.0 | |
| View Angle | 160 | 165 | 160 | 120 | 70-110 | 120 | |
| Dimension | Height | Up to 4,500 mm | Up to 3,200 mm | Up to 2,000 mm | Up to 3,600 mm | Up to 2,500 mm | Up to 4,800 mm |
| Width | No Limit(Depending on # of projectors) | ||||||
| Material(Color) | White | Gray | White/Silver | Silver | Silver | Dark Gray | |
| Seamless | Yes | Yes | Yes | Yes | Yes | Yes | |
| Frame Width | 8CM,10CM,15CM | ||||||
| 3D Capability | No | No | Silver with 3D | Yes | Yes | No | |
| Applications | Cinema, Video Presentation | Cinema | Cinema, Acoustically Transparent | Cinema, Simulation | Cinema, Simulation | Rear Projection | |
| Remarks | Floor Stand is optional | ||||||
