Live Streaming Ndi Video Broadcast PTZ Camera
Live streaming NDI Video Broadcast PTZ CameraMore NDI Camera can chooseFeaturesAdopting the advanced ISP, 1/2.8 inch 5MP sensor, providing users crystal clear video20x optical zoom+2x digital zoom, 61 degree field of view,idea for large space AV solutionIP Video Streaming, includes both H.264, H.265......
Send Inquiry
Product Description
Live streaming NDI Video Broadcast PTZ Camera
More NDI Camera can choose
Features
Adopting the advanced ISP, 1/2.8 inch 5MP sensor, providing users crystal clear video
20x optical zoom+2x digital zoom, 61 degree field of view,idea for large space AV solution
IP Video Streaming, includes both H.264, H.265 video encoding
1080p30 full HD Video over NDI|HX, 3G-SDI, HDMI, USB output video simultaneously
WDR, 3D Noise Reduction feature
Power over Ethernet: one single CAT5/6 to get video, control, tally and power
Live RTMP streaming, streaming to YouTuBe Live and Facebook Live directly
Special Focusing Algorithm: fast and precise focusing performance when zooming or moving
Smooth PTZ mechanical design, accurate pan tilt motor control
128 presets
Standard Sony VISCA, IP VISCA, PELCO-P, PELCO-D control protocol; IP VISCA over both TCP and UDP.
Daisy chain supported
Image flip function, support upside-down installation
Supplied with functional IR remote controller, can set IP address via OSD menu
Support multiple browsers to view video such as IE, Chrome, Firefox, Safari in both Mac and Windows system
Optional enclosure color: silver, grey, black, white
More NDI Camera can choose
Features
Adopting the advanced ISP, 1/2.8 inch 5MP sensor, providing users crystal clear video
20x optical zoom+2x digital zoom, 61 degree field of view,idea for large space AV solution
IP Video Streaming, includes both H.264, H.265 video encoding
1080p30 full HD Video over NDI|HX, 3G-SDI, HDMI, USB output video simultaneously
WDR, 3D Noise Reduction feature
Power over Ethernet: one single CAT5/6 to get video, control, tally and power
Live RTMP streaming, streaming to YouTuBe Live and Facebook Live directly
Special Focusing Algorithm: fast and precise focusing performance when zooming or moving
Smooth PTZ mechanical design, accurate pan tilt motor control
128 presets
Standard Sony VISCA, IP VISCA, PELCO-P, PELCO-D control protocol; IP VISCA over both TCP and UDP.
Daisy chain supported
Image flip function, support upside-down installation
Supplied with functional IR remote controller, can set IP address via OSD menu
Support multiple browsers to view video such as IE, Chrome, Firefox, Safari in both Mac and Windows system
Optional enclosure color: silver, grey, black, white
| Model No. | UHV-20X-IP-S(NDI) | |||
| Camera | ||||
| Sensor | 1/2.8" 5MegapixelCMOS Sensor | |||
| Video System | HDMI | NDI|HX | 3G-SDI | USB |
| 1920x10800p60/50/30/25 1280x720p60/50/30/25 1920x1080i60/50 | Main Steam: 1920x1080p30 1280x720p30 Sub Steam: 1280x720@30 1024x576@30 640x360@30 | 1920x1080p60/50/30/25 1280x720p60/50/30/25 1920x1080i60/50 | USB 3.0: 1920x1080p60/50/30/25 1280x720p60/50/30/25 1024x576p30 USB 2.0: 1024x576p30,960x540p30 640x360p30,352x288p30 | |
| Zoom | 20x optical zoom + 2x digital zoom | |||
| View Angle | 60.5° | |||
| F.no. | Wide: F1.5(Wide) - 3.0(Tele) | |||
| Focal Length | f=5.2(Near) - 98mm(Far) | |||
| Preset | 10 via remote controller; 128 via serial port; preset precision:0.1° | |||
| Pan Rotation Angle | - 170° - +170° | |||
| Tilt Roation Angle | - 30° - + 90° | |||
| Pan Rotation Speed | 0° - 120° /s | |||
| Tilt Rotation Speed | 0° - 80° /s | |||
| Control Port | NDI|HX RS232 / RS485 | |||
| Video Port | NDI|HX/3G-SDI/HDMI/USB3.0 | |||
| Network Speed | 1000M | |||
| Noise Reduction | 2D & 3D | |||
| SNR | Above 50dB | |||
| Minimum Lux | 0.01Lux | |||
| White Balance | Auto/Manual/Auto Tracking/OnePush/Indoor/Outdoor | |||
| Anti Flicker | 50Hz/60Hz/OFF | |||
| D/N Mode | Supported | |||
| Gamma | Supported | |||
| Mirror Image | Supported | |||
| Image Flip | Supported | |||
| Iris | Auto/Manual | |||
| Electric Shutter | Auto/Manual | |||
| Backlight Compensation | Atuo/Manual | |||
| Focus | Auto/Manual | |||
| Video Encoding | H.264/H.265 | |||
| Bit Rate Control | Variable BitRate, Constant Bit Rate | |||
| Video Bit Rate | 1024Kbps - 20480Kbps | |||
| Frames | 50HZ: 1fps - 30fps; 60HZ: 1fps - 30fps | |||
| IP Protocol | TCP/IP, HTTP,RTSP, RTMP, Onvif, DHCP,VISCA over IP(TCP&UDP),HTML5 | |||
| POE | Supported | |||
| Power | DC12V,2A | |||
| Dimension | 220mm x 173mm x 190mm | |||
| Net Weight | 1.25KGS(2.8LBS) | |||
