IP 4K 35X Optical Zoom HD Video Conference Ndi PTZ Camera USB3.0 HDMI 3G- SDI Audio Poe
IP 4K 35X Optical Zoom HD Video NDI PTZ CameraFeature1)Adopting the advanced ISP, 1/1.7 inch 12MP sensor, to provide 3840x2160p30 Ultra HD and crisp video with full details.2)Truly 4k lens: 35x optical zoom+2x digital zoom, 60 degree field of view.3)IP Video Streaming, includes both H.264, H.265 vid......
Send Inquiry
Product Description
IP 4K 35X Optical Zoom HD Video NDI PTZ Camera
Feature
1)Adopting the advanced ISP, 1/1.7 inch 12MP sensor, to provide 3840x2160p30 Ultra HD and crisp video with full details.
2)Truly 4k lens: 35x optical zoom+2x digital zoom, 60 degree field of view.
3)IP Video Streaming, includes both H.264, H.265 video encoding;
4)NDI|HX, 3G-SDI, HDMI, USB output video simultaneously, 4K video over NDI|HX and HDMl.
5)WDR, 3D Noise Reduction feature;
6) Power over Ethernet: one single CAT5/6 to get video, control, tally and power;
7)Live RTMP streaming, streaming to YouTuBe Live and Facebook Live directly.
8)Special Focusing Algorithm: fast and precise focusing performance when zooming or moving,
9)Smooth PTZ mechanical design, accurate pan tilt motor control;
10)Optional enclosure color: silver, grey, black, white.
11)Support multiple browsers to view video such as IE, Chrome, Firefox, Safari in both Mac and Windows system.
12) Supplied with functional IR remote controller, can set IP address via OSD menu;
NDI PTZ Camera are more and more popular now which are good used on the live steaming.
Feature
1)Adopting the advanced ISP, 1/1.7 inch 12MP sensor, to provide 3840x2160p30 Ultra HD and crisp video with full details.
2)Truly 4k lens: 35x optical zoom+2x digital zoom, 60 degree field of view.
3)IP Video Streaming, includes both H.264, H.265 video encoding;
4)NDI|HX, 3G-SDI, HDMI, USB output video simultaneously, 4K video over NDI|HX and HDMl.
5)WDR, 3D Noise Reduction feature;
6) Power over Ethernet: one single CAT5/6 to get video, control, tally and power;
7)Live RTMP streaming, streaming to YouTuBe Live and Facebook Live directly.
8)Special Focusing Algorithm: fast and precise focusing performance when zooming or moving,
9)Smooth PTZ mechanical design, accurate pan tilt motor control;
10)Optional enclosure color: silver, grey, black, white.
11)Support multiple browsers to view video such as IE, Chrome, Firefox, Safari in both Mac and Windows system.
12) Supplied with functional IR remote controller, can set IP address via OSD menu;
| Model No. | UHV-500-H(NDI) | |||
| Camera | ||||
| Sensor | 1/1.7" 12MegapixelCMOS Sensor | |||
| Video System | HDMI | NDI | 3G-SDI | USB |
| 3840x2160p30/25 1920x10800p60/59.94/50/30/29.97/25/24 1920x1080i60/59.94/50 1280x720p60/59.94/50/30/29.97/25 | Main Steam: 3840x2160p30 1920x1080p30 Sub Steam: 1280x720@30 1024x576@30 640x360@30 | 1920x1080p60/59.94/50/30/29.94/25/24 1920x1080i60/59.94/50 1280x720p60/59.94/50/29.97/30/25 | USB 3.0: 1920x1080p60/50/30/25 1280x720p60/50/30/25 1024x576p30 USB 2.0: 1024x576p30,960x540p30 640x360p30,352x288p30 | |
| Zoom | 35x optical zoom + 2x digital zoom | |||
| View Angle | 2.02° (wide) - 60° (tele) | |||
| Focal Length | f=5.8(Near) - 203mm(Far) | |||
| SNR | Above 50dB | |||
| Minimum Lux | 0.01Lux | |||
| Focus | Auto/Manual | |||
| Min.Focus Distance | Wide: 0.3m Tele:1.5m | |||
| Iris | Auto/Manual | |||
| Iris No. | Wide: 1.5 Tele: 4.8 | |||
| White Balance | Auto/Manual/Auto Tracking/OnePush/Indoor/Outdoor | |||
| Electric Shutter | Auto/Manual | |||
| Backlight Compensation | Atuo/Manual | |||
| Noise Reduction | 2D & 3D | |||
| D/N Mode | Supported | |||
| Gamma | Supported | |||
| Mirror Image | Supported | |||
| Image Flip | Supported | |||
| PanTilt Flip | Supported | |||
| Anti Flicker | 50Hz/60Hz/OFF | |||
| Video Freeze | Supported | |||
| Mechanical | ||||
| Preset | 10 via remote controller; 128 via serial port; preset precision:0.1° | |||
| Pan Rotation Angle | - 170° - +170° | |||
| Tilt Roation Angle | - 30° - + 90° | |||
| Pan Rotation Speed | 0° - 120° /s | |||
| Tilt Rotation Speed | 0° - 80° /s | |||
| Control Port | NDI|HX RS232 / RS485 /USB3.0 | |||
| Video Port | NDI|HX/3G-SDI/HDMI/USB3.0 | |||
| Power | DC12V,2A | |||
| POE | Supported | |||
| Dimension | 220mm x 173mm x 190mm | |||
| Net Weight | 1.25KGS(2.8LBS) | |||
| Encoding | ||||
| Video Encoding | H.264/H.265 | |||
| Bit Rate Control | 1024Kpbs - 20480Kbps | |||
| Video Bit Rate | 1024Kbps - 20480Kbps | |||
| Frames | 50HZ: 1fps - 50fps; 60HZ: 1fps - 60fps (3840 x 2160 max.30fps) | |||
| IP Protocol | TCP/IP, HTTP,RTSP, RTMP, Onvif, DHCP,VISCA over IP(TCP&UDP),HTML5 | |||
| Network Speed | 1000M | |||
| Supported Browser | Chrome, Safari, Firefox,IE~~~~ | |||
NDI PTZ Camera are more and more popular now which are good used on the live steaming.
